Uni-Fit™

Specification:

Fixed Polycarbonate LED Downlights

ThermoTec™ heat management technology
Delivering up to 117lm/W
Pre-wired with 500mm 2 core cable
Opal polycarbonate diffuser for even light distribution
Supplied with integrated driver

Cat. No.	Watts	lm/W	Lumens	Colour	Beam
Non-Dimmable
EN-DL10-30	10W	105	1050lm	3000K	100°
EN-DL10-40	10W	115	1150lm	4000K	100°
EN-DL15-30	15W	107	1600lm	3000K	100°
EN-DL15-40	15W	113	1700lm	4000K	100°
EN-DL23-30	23W	108	2500lm	3000K	100°
EN-DL23-40	23W	117	2700lm	4000K	100°
EN-DL30-30	30W	106	3200lm	3000K	100°
EN-DL30-40	30W	115	3450lm	4000K	100°
Triac Dimmable
EN-DDL10-30	10W	90	900lm	3000K	100°
EN-DDL10-40	10W	96	960lm	4000K	100°
EN-DDL15-40	15W	96	1450lm	4000K	100°
EN-DDL20-40	20W	105	2100lm	4000K	100°
EN-DDL25-40	25W	102	2550lm	4000K	100°

Black option available as a special order, contact sales office for more information
