Zenith™

Specification:

3 Circuit Aluminium LED Track Lighting

Compact styling with powerful outputs, Zenith™ is ideal for retail and display lighting
Delivering up to 130lm/W
CRI 90 for high colour rendering accuracy
24°, 36° and 50° beam angle options available
Dimmable versions available on request
355° rotation and 90° horizontal adjustment
2kV surge protection

Product Categories

Cat. No.
Wattslm/WLumensColourBeamSpec SheetsIES Files
CRI80
AA-TSZ288036-30*
28W1273550lm3000K36°DownloadDownload
AA-TSZ288036-35*
28W1293600lm3500K36°DownloadDownload
AA-TSZ288036-40*
28W1303620lm4000K36°DownloadDownload
CRI90
AA-TSZ289036-30*
28W1203350lm3000K36°DownloadDownload
AA-TSZ289036-35*
28W1213400lm3500K36°DownloadDownload
AA-TSZ289036-40*
28W1223420lm4000K36°DownloadDownload

*Add suffix W or BLK for White or Black finish
Replace 36 with 24 or 50 in sku code for alternative beam angles options
Triac, Dali, 1-10V dimmable options available, contact sales office for more information

Reflectors
Cat. No.
Beam
Watts
AA-TSZA2824
24°28W
AA-TSZA2836
36°28W
AA-TSZA2850
50°28W

Restore your product at the end of it’s life cycle

The Enfiniti™ range of track lights allows the customer to change the COB (Chip on Board) light source and driver at the end of its life offering significant benefits. This capability ensures the longevity and sustainability of the lighting system, as users can replace only the expired components rather than the entire fixture, which is both cost-effective and environmentally friendly.

Replaceable COB at end of life (Zhaga)

Replaceable driver

Changeable reflectors 24°, 36° & 50° beam angles
