Specification:
Wattage & Colour Selectable Low Glare Downlights
Colour temperature can be switched between 3000K and 4000K
Wattage selectable
Designed for a variety of applications, ideal for retrofit solutions with a wide range of cutouts available
Delivering up to 135lm/W
Low UGR reflector
Flicker free
1.5kV surge protection
| Cat. No. | Watts | lm/W | Lumens | Colour | Beam | Spec Sheets | IES Files |
|---|---|---|---|---|---|---|---|
| 4" | |||||||
AA-DLNWS4-CS* | 5W / 6W / 7W / 8W | up to 113 | 510lm - 900lm | 3000K / 4000K | 60° |  | |
| 6" | |||||||
AA-DLNWS6-CS* | 6W / 8W / 10W / 12W / 13W | up to 123 | 650lm - 1600lm | 3000K / 4000K | 60° | | |
| 8" | |||||||
AA-DLNWS8-CS* | 10W / 12W / 15W / 17W / 20W | up to 125 | 1100lm - 2500lm | 3000K / 4000K | 60° | | |
| 10" | |||||||
AA-DLNWS10-CS* | 18W / 20W / 22W / 25W / 30W | up to 135 | 2160lm - 4100lm | 3000K / 4000K | 60° | | |
*Add suffix W or BLK for White or Black finish
Triac, Dali, 1-10V dimmable & EM options available, contact sales office for more information
